Tohnichi Reference Guide 2019
CD5 Compact Display ? Digital display for Tohnichi?s torque sensor, strain gauge, products
Direct Reading
Sensor Contacts
Digital
Judgment
Comparator
Optional Equipment ? Easy to con?rm judgment with blue and red digits displayed
? OK or NG judgment capability with upper or lower limit setting function
Display
Negative type liquid crystal
Model
CD5
±1/5000 (±1.0 to ±3.0mV/V)
1/2000 (+0.1 to +3.0mV/V)
±3.0mV/V
Input Voltage
CD5 Optional Accessories Resolution ±1/2000 (±0.5 to ±1.0mV/V)
Nonlinearity ±0.05% F.S.
Accuracy Zero point drift ±0.1?V/°C (TYP.)
Printer Gain drift ±0.01%/°C (TYP.)
Model Equivalent input calibration
EPP16M3 Calibration Methods Calibration by actual weight
Calibration using sensor-equipped torque
wrench
Data Filing System Data Memory 1000 readings
CD5 External Input RESET/COMP/CLEAR/CHSW
Model Media
DFS CD-ROM Communication RS232C compliant, Analog output, HI.
OK, LO relay output
Power AC100-240V±10%
Connecting Cable (P.46) Operating Temperature 0-40 °C
Part # Applicable Model Plug Dimension 150W × 190D × 94H
383 CD5 - PC, EPP16M3 D-SUB 9 Pin Female Weight approx. 1.8 kg
TPC Protocol Auxiliary RS232C/LAN Data Output
Converter
? Convert Tohnichi interface device format to other protocols
? Incorporate time and VIN data with tightening record by the internal clock and
an optional barcode reader
NEW
Model Input/Output LAN x 1, RS232C x 2
TPC Power Status LED x 1,
Display
Communication status LED x 1
Note Applicable
To use custom made protocol function, Tohnichi Interface R-FH256, R-BLA, R-BLE, R-BT, CD5, R-FHD256
required prior consult ATLAS COPCO® ACOP Serial connection,
ATLAS COPCO® ACOP Socket connection,
Protocols
STANLEY®
Custom made Protocol*
Optional Accessories Data Output LAN, Serial Port
Power DC24V 18V to 38V
AC Adapter Dimensions W82 × D33 × H80mm
Operating Temperature 0-40 °C
Model Power Supply Weight 146g
BA-8W AC100V-240V
ATLAS COPCO is registered trademark of Atlas Copco Aktiebolag
STANLEY is registered trademark of Stanley Logistics, LLC
R-DT999 Data Tank Auxiliary Infrared Input RS232C/ Data Output
? Infrared data collector for torque equipment
? 999 data storage
? External keypad setup functions
Model Data Input Infrared data input (Tohnichi format only)
R-DT999 6 digits, 14segments LCD
Display 4 digits, 7segments LCD
R-DT999 Optional Accessories Applicable Model 4 digits, 7segments LED
CEM3-G, CEM2, ST, ST2, STC, CTA, CTB
Printer Data Output RS232C compliance,
Model USB connector serial output (*USB 1.1)
EPP16M3 Power DC5V 2A
Dimensions W80 × D125 × H32mm
Standard Accessories AC adapter (100-240V±10%)
Data Filing System Operating Temperature 0-40 °C
Model Media Weight 205g (body only)
DFS CD-ROM
R-DT999
Connecting Cable (P.46)
Part # Applicable Model Plug
575 R-DT999 - PC, EPP16M3 D-SUB 9 Pin Female
584 R-DT999 - PC USB A Type
Note Contact Tohnichi for other types of connector shapes.
DFS Data Filing System/ Auxiliary CD
? Data processing software
? Statistics, Standard deviation, Cp values, Charts
Model Maximum value, minimum value, data range, mean value,
ST3-G TME2
DFS standard deviation and Cp value are calculated to make a
CD5
CEM3-G histogram on the display.
DFS
