Tohnichi Reference Guide 2019
TCF Fixed Type Torque ? Requires CD5 to display torque reading RoHS
Fixed
Voltage Output
Sensor
Torque Range Torque Range Torque Range Inlet Dimensions
S.I. Model [N·m] Metric [kgf·cm] American [lbf·in/lbf·ft] Drive Height Diamater Weight
Model
Model
Min.-Max. Min.-Max. Min.-Max. [mm] [mm] [mm] [kg]
lbf·in
TCF02N 0.02-0.2 TCF1.8 0.18-1.8 TCF1.8I 0.18-1.8 56 0.45
TCF04N 0.04-0.4 - - TCF3.5I 0.35-3.5
TCF1N 0.1-1 TCF9I 0.9-9.0 6.35 45
TCF2N 0.2-2 TCF18 1.8-18 TCF18I 1.8-18 62.5 0.5
TCF4N 0.4-4 - - TCF35I 3.5-35
TCF10N 1-10 TCF90I 9.0-90
TCF20N 2-20 TCF180 18-180 TCF180I 18-180 9.5 66 70 0.6
TCF40N 4-40 TCF350I 38-350
CD5 TCF20N
- - lbf·ft
*Display is sold separately. TCF100N 10-100 TCF75F 7.5-75 12.7 100 105 2.5
TCF200N 20-200 TCF1800 180-1800 TCF150F 15-150
TCF400N 40-400 - - TCF300F 30-300 19.0 135 140 6
TCF1000N 100-1000 TCF750F 75-750 25.4 180 178 12
TCF2000N 200-2000 TCF18000 1800-18000 TCF1500F 150-1500
Note 1. TCL, calibration kit is optional.
2. Display, CD5, is sold separately.
Standard Accessories Connecting Cable
TCF Optional Accessories TP, Test Piece: Torque measurement for power torque tools
Torque Range Inlet Dimensions
S.I. Metric American Applicable Width Across Nominal Weight
Model Diameter Height
[N·m] [kgf·cm] [lbf·in/lbf·ft] TCF Model Flats Size of
Min.-Max. Min.-Max. Min.-Max. [mm] Screw [mm] [mm] [kg]
lbf·in
TP2.5N 0.25-2.5 2.5-25 2-22 TCF02N-TCF4N 8 M4 18 58 0.08
TP18N 1.8-18 18-180 16-160 TCF10N, TCF20N 13 M6 35 83.5 0.27
lbf·ft
TP180N 18-180 180-1800 30-130 TCF40N-TCF200N 24 65 148 1.9
TP18N+TCF20N TP1800N 180-1800 1800-18000 130-1300 TCF400N-TCF2000N 50 - 140 297.5 16.8
Note 1. Adapter 4H-3 (#273) is necessary for TCF40N.
2. Adapter 8P-6 (#295) is necessary for TCF400N.
DTF, Drill Chuck: Torque measurement for axial work pieces
Dimensions
Chuck Size Square Drive
Model Applicable TCF Models Diamater Height
[mm] [mm] [mm] [mm]
DTF5-2+TCF20N DTF5-3 TCF02N-TCF4N Max. ?5 6.35 33 65
DTF5-2 TCF10N-TCF40N 9.5 61
TTF/ATF, Table and ?xture: Ideal for testing torque on bottle caps
Model Applicable TCF Chuck Size Table Dia.
TTF ATF [mm] [mm]
TTF7 ?10-70 ?70
ATF18-2 TCF02N-TCF4N
TTF11 ?14-110 ?110
ATF18 TCF10N-TCF20N
ATF18-2 TCF2N-TCF4N
TTF19 ?18-190 ?180
TTF11+ATF18+TCF20N ATF18 TCF10N-TCF20N
Note ATF attachment is required to ?x TTF table.
TCR Rotary Type Torque Voltage Output Rotary RoHS
Sensor
? Captures directly applied torque
? Requires CD5 to display torque reading
Torque Range Torque Range Torque Range Allowable Square Torque Tester/Checker
S.I. Model [N·m] Metric [kgf·cm] American [lbf·in/lbf·ft] Rotation Drive Height Width Weight
Model
Model
Min.-Max. Min.-Max. Min.-Max. [r.p.m] [mm] [mm] [mm] [kg]
lbf.in
TCR18N 1.8-18 TCR180 18-180 TCR180-A 16-160 9.5 91 76 0.9
lbf.ft 2000
TCR180N 18-180 TCR1800 180-1800 TCR1800-A 13-130 12.7 104 83 1.3
TCR700N 70-700 TCR7000 700-7000 TCR7000-A 50-500 1000 19.0 118.5 95 2.0
TCR1800N 180-1800 TCR18000 1800-18000 TCR18000-A 130-1300 25.4 138.5 110 3.6
CD5 TCR18N 1. TCL, calibration kit is optional.
*Display is sold separately. Note 2. Display, CD5, is sold separately.
Standard Accessories Connecting Cable
Calibration Kit for TCF/TCR
* Sold separately.
Refer to page 59.
