Tohnichi Reference Guide 2019
TME2 Digital Torque Meter ? Ideal for testing torque on bottle caps RoHS
Digital
Pole Clamping
Direct Reading
Direction ? Up to 99 measured data can be stored.
Accuracy ±1%+1digit
Torque Range Torque Range Torque Range Chuck Dimensions [mm]
S.I. Model [cN·m] Metric [gf·cm/kgf·cm] American [ozf·in/lbf·in] Size Overall Width Height Weight
Model
Model
Min.-Max. 1 digit Min.-Max. 1 digit Min.-Max. 1 digit [mm] Length [kg]
gf·cm gf·cm ozf·in ozf·in
3TME10CN2 2.00-10.00 0.01 3TME10CN2-M 200-1000 1 3TME10CN2-Z 2.80-14.00 0.01
3TME20CN2 4.00-20.00 0.02 3TME20CN2-M 400-2000 2 3TME20CN2-Z 5.60-28.00 0.02 ?14-
3TME50CN2 10.00-50.00 0.05 3TME50CN2-M 1000-5000 5 3TME50CN2-Z 14.00-70.00 0.05 ?110 252 158 185 3.5
kgf·cm kgf·cm
3TME100CN2 20.0-100.0 0.1 3TME100CN2-M 2.00-10.00 0.01 3TME100CN2-Z 28.00-140.0 0.1
lbf·in lbf·in
2TME200CN2 40.0-200.0 0.2 2TME200CN2-M 4.00-20.00 0.02 2TME200CN2-I 3.50-17.00 0.02
2TME500CN2 100.0-500.0 0.5 2TME500CN2-M 10.00-50.00 0.05 2TME500CN2-I 8.80-44.00 0.05 ?18- 331 223 283 12
2TME1000CN2 200-1000 1 2TME1000CN2-M 20.0-100.0 0.1 2TME1000CN2-I 17.6-88.00 0.1 ?190
2TME2000CN2 400-2000 2 2TME2000CN2-M 40.0-200.0 0.2 2TME2000CN2-I 35.0-175.0 0.2
Note 1. Can be used for checking accuracy of torque screwdrivers.
2. Max. 99 measured data can be stored.
3. TMTCL, calibration kit is optional.
4. Statistical Data: Hi, Lo, Sample, Ave., Range Variation, and Standard Deviation
Standard Accessories 1. AC Adapter/BA-4
2. Rubber Nail
3. Supportive Plate for 2TME2
TME2 Optional Accessories
2TME500CN2
Connecting Cable (P.46) Printer (P.64)
Part # Applicable Model Model
383 TME2 - PC, EPP16M3 EPP16M3
Battery Pack (P.46) Data Filing System (P.63)
Model Model Media
BP-100-4 DFS CD-ROM

TM Analog Torque Meter Pole Clamping Direct Reading RoHS
? Dial indicating
Direction ? Wide variety of torque testing ranges
Accuracy ±2%
Torque Range American Torque Range Metric Torque Range Dimensions [mm]
S.I. Model American/Metric Weight
[mN·m/cN·m] Model [lbf·in] [kgf·cm/gf·cm] Overall Chuck
Standard With Memory Pointer Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. Length Width Height Size [kg]
mN·m mN·m gf·cm gf·cm
4TM10MN 4TM10MN-S 1-10 0.2 4-TM100-A-S 0.01-0.086 0.002 10-100 2
4TM15MN 4TM15MN-S 1.5-15 4-TM150-A-S 0.02-0.13 15-150
4TM25MN 4TM25MN-S 2.5-25 0.5 4-TM250-A-S 0.025-0.215 0.005 25-250 5
4TM50MN 4TM50MN-S 5-50 1 4-TM500-A-S 0.05-0.43 0.01 50-500 10
4TM75MN 4TM75MN-S 8-75 2 4-TM750-A-S 0.08-0.65 0.02 80-750 20 ?14-
cN·m cN·m kgf·cm kgf·cm 252 158 109.5 3
3TM10CN 3TM10CN-S 1-10 0.2 3-TM1-A-S 0.1-0.86 0.02 0.1-1 0.02 ?110
3TM15CN 3TM15CN-S 1.5-15 0.5 3-TM1.5-A-S 0.15-1.3 0.05 0.15-1.5 0.05
2TM400CN 3TM25CN 3TM25CN-S 2.5-25 3-TM2.5-A-S 0.25-2.15 0.25-2.5
3TM50CN 3TM50CN-S 5-50 1 3-TM5-A-S 0.5-4.3 0.1 0.5-5 0.1
3TM75CN 3TM75CN-S 10-100 2 3-TM7.5-A-S 0.8-6.5 0.2 0.8-7.5 0.2
8-75
2-TM10-A-S
Torque Tester/Checker 5TM2.5MN 2TM200CN 2TM200CN-S 30-200 10 5 2-TM20-A-S 3.5-35 0.5 3-20 0.5 331 223 133.5 ?18- 10.5
1-10
1-8.6
2TM100CN 2TM100CN-S
0.2
0.2
2TM150CN 2TM150CN-S
2-13
20-150
2-15
2-TM15-A-S
3-17
3-26
2-TM30-A-S
30-300
2TM300CN 2TM300CN-S
3-30
?190
2-TM40-A-S
4-40
2TM400CN 2TM400CN-S
40-400
5-50
2-TM50-A-S
4-43
50-500
2TM500CN 2TM500CN-S
60-600
6-60
5-50
1
2TM600CN 2TM600CN-S
2-TM60-A-S
1
7-65
80-750
2TM750CN 2TM750CN-S
8-75
2-TM75-A-S
Calibration Kit for TME2/TM
* Sold separately. Note ?-S? models are provided with a memory pointer.
Refer to page 59. Low Capacity, below 7.5 mN·m, Torque Meter
Accuracy ±2%
Torque Range Torque Range Torque Range Dimensions [mm]
S.I. Model [mN·m] Metric [gf·cm] American [ozf·in] Overall Width Height Chuck Weight
Model
Model
Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. Length Size [kg]
5TM1MN 0.2-1 0.05 5-TM10 2-10 0.5 5-TM015Z 0.02-0.15 0.005
5TM1.5MN 0.2-1.5 5-TM15 2-15 5-TM020Z 0.04-0.2
?6-
5TM2.5MN 0.5-2.5 0.1 5-TM25 5-25 1 5-TM035Z 0.05-0.35 0.01 122 76.5 59 ?58 0.3
5TM5MN 1-5 5-TM50 10-50 5-TM070Z 0.3-0.7 0.02
5TM7.5MN 1-7.5 0.2 5-TM75 10-75 2 5-TM1Z 0.2-1 0.05
Note 1. 5TM models are supplied without memory pointer.
2. When calibrating the 5TM models, ask Tohnichi for assistance.
