Tohnichi Reference Guide 2019
ATG/BTG Analog Torque ? Compact portable handheld design RoHS
Direct Reading
Dial Indicating
3-jaw Chuck
Gauge
Direction ? Top and side scales for easy reading
? Three ?ngered keyless chuck
Accuracy ±2%
Torque Range Torque Range Torque Range Chuck Dimensions [mm]
S.I. Model [cN·m] Metric [gf·cm/kgf·cm] American [ozf·in/lbf·in] Grip Overall Outside Weight
Model
Model
Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. [mm] Length Diameter [kg]
gf·cm gf·cm ozf·in ozf·in
ATG045CN 0.05-0.45 0.01 45ATG 5-45 1 ATG06Z 0.06-0.6 0.01
ATG09CN-S 0.1-0.9 90ATG-S 10-90 ATG1.5Z-S 0.2-1.5 0.02
ATG1.5CN-S 0.2-1.5 0.02 150ATG-S 20-150 2 ATG2.4Z-S 0.3-2.4 0.05 ?1-
ATG3CN-S 0.3-3 0.05 300ATG-S 30-300 5 ATG4.5Z-S 0.5-4.5 0.1 89 43.5 0.18
ATG6CN-S 0.6-6 0.1 600ATG-S 60-600 10 ATG9Z-S 1-9 0.2 ?6.5
ATG12CN-S 1-12 0.2 1200ATG-S 100-1200 20 ATG18Z-S 2-18 0.5
ATG24CN-S 3-24 0.5 2400ATG-S 300-2400 50 ATG36Z-S 4-36 0.5
ATG6CN BTG36CN - - - - - - BTG60Z-S 6-60 1
- - - - - - BTG120Z-S 10-120 2
kgf·cm kgf·cm lbf·in lbf·in
BTG15CN-S 2-15 0.2 1.5BTG-S 0.2-1.5 0.02 1.5BTG-A-S 0.1-1.5 0.02 ?1-
ATG Optional Accessories BTG24CN-S 3-24 0.5 2.4BTG-S 0.3-2.4 0.05 2.4BTG-A-S 0.3-2.4 0.02 ?8.5 119 64.2 0.52
BTG36CN-S 4-36 3.6BTG-S 0.4-3.6 3.6BTG-A-S 0.4-3.6 0.05
Part # Description BTG60CN-S 6-60 1 6BTG-S 0.6-6 0.1 6BTG-A-S 0.6-6 0.1
322 Plastic Case and Chuck BTG90CN-S 10-90 9BTG-S 1-9 9BTG-A-S 1-9 0.1
BTG150CN-S 20-150 2 15BTG-S 2-15 0.2 15BTG-A-S 2-15 0.2
Note 1. ATG045CN, 45ATG and ATG06Z are provided without side or top memory pointer.
2. ?Without memory pointer? models are available. Remove ?-S? from the model name when ordering.
Ex. ATG09CN, BTG15CN
3. Aluminum case and steel chuck are standard for ATG models. Plastic case and chuck can be ordered separately.
ATGE-G Digital Torque Digital 3-jaw Chuck Direct Reading Battery RoHS
Gauge
Direction ? Digital torque gauge with pull out display
? For measurement, inspection and tightening of low torque range
? 3 way con?guration; hand-held, table top or as a torque meter with testing
?xture
Accuracy ±2%+1digit
Torque Range Chuck Dimensions [mm]
Model [cN·m] [mN·m] [gf·cm] [ozf·in] Grip Overall Outside Weight
Min.-Max. 1 digit Min.-Max. 1 digit Min.-Max. 1 digit Min.-Max. 1 digit [mm] Length Diameter [kg]
ATGE05CN-G 0.1-0.5 0.001 1-5 0.01 10-50 0.1 0.15-0.7 0.001
ATGE1CN-G 0.2-1 0.001 2-10 0.01 20-100 0.1 0.3-1.4 0.001
ATGE2CN-G 0.4-2 0.002 4-20 0.02 40-200 0.2 0.6-2.8 0.002
ATGE5CN-G 1-5 0.005 10-50 0.05 100-500 0.5 1.5-7 0.005 ?1-6.5 120 67 0.305
ATGE10CN-G 2-10 0.01 20-100 0.1 200-1000 1 3-14 0.01
ATGE20CN-G 4-20 0.02 40-200 0.2 400-2000 2 6-28 0.02
Note Aluminum case and steel chuck are standard for ATGE-G models. Plastic case and chuck/322 (page 56) is
sold separately.
Standard Accessories Carrying case
ATGE5CN-G
ATGE-G Common Speci?cations
Direction CW/CCW
7 segment LCD display,
Calibration Kit for Display Counter 3 digits (character height 3mm),
Torque value: 4 digits (character height 7mm)
ATG/BTG/ATGE-G/BTGE-G
Torque unit, Battery indicator, Direction
Torque Tester/Checker * Sold separately. Data Memory 999 readings
Mode
PEAK/RUN
Refer to page 59.
Sample size, Max. value, Min. value, Mean value
Statistic Prosessing
USB output (USB mini B connector)
Data Output
Coin-type lithium battery (CR2450)
Power
Continuous in Use
approx. 10 hours when using coin battery
Auto power off (3 min.), Auto memory reset (0.5-5) seconds variable, Auto zero adjustment,
Other Functions
Operating Temperature
0-40 °C
Standard Options Residual battery indicator (4 steps), Buzzer ON/OFF, Unit Conversion
Carrying case
ExRcv Software
The ExRcv software allows for the transfer of collected torque data from various
Tohnichi digital torque equipment into a Microsoft® Excel® worksheet.
Tohnichi also provides customized software upon request.
ExRcv
