Tohnichi Reference Guide 2019
DOTE4-G-MD2 RoHS

Direction Digital Torque Wrench Tester ? Suitable for large volume of calibrations
with Motor Driven Loader ? Control loader with motor drive
? Motor drive can be retro?tted to DOTE4-G tester

DOTE500N4-G-MD2
Controller unit with speed adjusting and inching function

DOTE4-G-MD2 MD2-SET
Complete Tester with Motor Drive Set Retro?t Motor Driven Unit

Model Construction unit
DOTE20N4-G-MD2 Model Motor Unit w/Limiter Controller Unit Power Unit Power Cord Applicable Model
DOTE50N4-G-MD2 MD2-SET-SA PC-MD2A
DOTE100N4-G-MD2 MD2-SET-SC M-MD2-S DR-MD2-S PC-MD2C DOTE20N4-G to 200N4-G
DOTE200N4-G-MD2 MD2-SET-LA C-MD2 PC-MD2A
DOTE500N4-G-MD2 MD2-SET-LC M-MD2-L DR-MD2-L PC-MD2C DOTE500N4-G, 1000NN4-G
DOTE1000N4-G-MD2
Note 1. PC-MD2A come with A type plug for 100 - 125V.
PC-MD2C come with C type plug for 100 - 240V.
Note
Select the plug shape A or C type when ordering.

Calibration Kit for DOTE4-G
* Sold separately.
Refer to page 59-60. M-MD2-S C-MD2 DR-MD2-S PC-MD2A
Motor and Limit Switch Controller Motor power unit Power cord
TCC2-G Digital Torque Calibration Digital Manual Handle Direct Reading
Wrench Tester
Direction ? Torque calibrator with data management software with wide torque range
? Calibration, adjustment, and data management for torque wrenches
? Multiple measuring unit
? Controlled by Tablet PC
MEASUREMENT 13/8/9 14:00
Serial Number Model Name Ch Accuracy (%) Click Type
esc TOH000-A12345 CEM100N3X15D 1 3.0 Accuracy ±1%+1digit
0.0000
Zero N.m
Set Torque 1 2 3 4 5
Clear 20.000 20.000 20.000 20.000 20.000 20.000
40.000 40.000 44.000 40.000 40.000 40.000 Dimensions
MEMORY 60.000 60.000 60.000 60.000 63.500 60.000 Torque Wrench
80.000 80.000 80.000 80.000 80.000 80.000
100.00 100.00 100.00 100.00 100.00 Torque Range Torque Range Torque Range [mm]
Model CH [N·m] [kgf·cm] [lbf·in] Max. Effective Inlet Drive Weight
Length Overall
Min.-Max. 1 digit Min.-Max. 1 digit Min.-Max. 1 digit [mm] [mm] Length Width Height [kg]
1 4-100 0.01 40-1000 0.1 35.5-885 0.1 575 12.7
TCC100N2-G Torque Tester/Checker
2 1-25 0.002 10-250 0.02 9-220 0.02 482 9.53 714 388 375 35
1 4-100 0.01 40-1000 0.1 35.5-885 0.1 575 12.7
TCC100N2-D-G
2 20-600 cN·m 0.05 cN·m 2-60 0.005 2-50 0.005 482 6.35
1 20-500 0.05 200-5000 0.5 180-4400 0.5 1035 19.05
TCC500N2-G 1206 502 430 75
2 4-100 0.01 40-1000 0.1 36-880 0.1 769 12.7
1 50-1000 0.1 500-10000 1 445-8800 1 1700 25.4
TCC2-G Standard Accessories TCC1000N2-G 2 20-500 0.05 200-5000 0.5 180-4400 0.5 1212 19.05 1906 574 526 115
Down
Model Hex Adapter Others
Adapter TCC2-G Specifications
TCC100N2-G 12.7-W10, 13, 19 DA3-2 Display 10 inch Tablet PC
DA4-3
12.7-W12, 14, 17
TCC100N2-D-G DA4-3 (1) Cradle for Torque wrench/driver registration date, measurement date memory (model, serial number,
measurement point, measurement count, accuracy level, channel, measurer, past record)
12.7-W10, 13, 19 PC display Tool Management Function Maximum data amount (1000pcs worth) is based on testing torque wrenches of single force
12.7-W12, 14, 17 DA4-3 (2) AC adapter
TCC500N2-G 19.05-W17, 22, 27 DA6-4 for PC direction.
19.05-W19, 24, 30 display When testing bi-direction torque wrenches such as BQSP, it will be less than 1000pcs)
19.05-W17, 22, 27 (3) Power Measurement Mode Click mode / direct reading mode / manual mode
cable
Automatic (press C key)
Zero Adjustment
TCC1000N2-G 19.05-W19, 24, 30 DA6-4
25.4-W36, 46 DA8-6 Operating Temperature 0 ~ 40 °C
25.4-W41, 50 Power 100 ~ 240V 50/60Hz
Note Refer to page 64.
Calibration Kit for TCC2-G
* Sold separately. Refer to page 59.
52
