Tohnichi Reference Guide 2019
DU Fully-Automatic Electric ? Easy torque set with external scale Graduation Trigger RoHS
Electric
Assembly
Straight
Torque Screwdriver
? Blushless motor : high durability and low noise
Direction
? Ideal for torque traceability
? Control the number of tightening to eliminate missed tightening
Accuracy ±5%
Torque Range Free Speed Applicable Screw size Overall
S.I. Model [cN·m] [r.p.m] (Ref.) Length Weight
Min.-Max. Grad. High Low Standard High-strength [mm] [kg]
cN·m cN·m
DU30CN 10-30 0.5 1500 1050 M2 (M2.2) (M1.8) M2
DU60CN 20-60 1 M2.5, M3 (M2.2) M2.5 281 0.6
DU250CN DU100CN 40-100 2 1400 980 (M3.5) M3 (M3.5)
DU250CN 100-250 5 1200 840 M4 (M4.5) M4 305 0.82
Note 1. Cable and DU-Counter are required and sold separately.
2. TCF is available as a checker. Refer to page 58.
DU-COUNTER Specifications 3. Counterclockwise rotation has no torque control. It is loosening purpose only.
Model DU-COUNTER Double tightening prevention/1-99 sec.
Counter Display 2 digits 7 segments Timer Function Auto-reset/0-60 sec.
Judgement Blue/Red Interval warning/0-99 sec.
Number of Tightening 1-99 Power Source AC100V-240V±10% 50/60Hz 3.6A MAX
Judgement Mode Preset, Automatic judgment - 0~99 seconds/per sec. Output Voltage DC36V 13.4A MAX
OK/NG output, Dimension W159.2 × D220 × H83
Output Weight [kg] 1.3
Relay contact: DC30V 1A, AC125V 0.3A
Input RESET input Operating Temperature [°C] 0-40
Accessories AC cable
Cable for DU and DU-COUNTER Applicable Model DU30/60/100/250CN DU-COUNTER
Part # Applicable Model Length [m]
516 DU and DU-COUNTER 2
517 5 Cable for DU/DU-Counter

U/UR UNITORK/Straight & Assembly Straight/Pistol Pneumatic Graduation Trigger/Lever RoHS
Pistol Type Pneumatic
Direction Torque Screwdriver ? Accurate and stable tightening for small size screws
? Lever activated
Accuracy ±5%
Torque Range Torque Range Torque Range Free Air Hose Standard
S.I. Model [cN·m] Metric [kgf·cm] American [lbf·in] Speed Pressure in Dia. Weight Accessory
Model
Model
U UR Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. [r.p.m] [MPa] [mm] [kg] Bit +
cN·m cN·m kgf·cm kgf·cm lbf·in lbf·in
U30CN 10-30 0.5 U3 1-3 0.05 U3-A 1-3 0.05 1600 0.4 0.32 #0
U60CN 20-60 1 U6 2-6 0.1 U6-A 2-5 0.1 1700 0.5 ?5 0.42 #1
U120CN 40-120 2 U12 4-12 0.2 U12-A 4-10 0.2 1400 0.48
U250CN 100-250 5 U25 10-25 0.5 U25-A 8-22 0.5 1200 0.6 0.75 #2
U500CN 200-500 U50-2 20-50 U50-2-A 15-45 950 0.5 ?6 1.35
U1000CN 400-1000 10 U100 40-100 1.0 U100-A 30-90 1.0 700 0.6 2.0 #3
ULR120CN 40-120 2 U12LR 4-12 0.2 U12LR-A 4-10 0.2 1300 0.5 ?5 0.56
ULR250CN 100-250 1. U1000CN has a ?xed square drive (9.53mm). Use socket bits or bit holders for this model. 0.95 #2
1000
10-25
0.5
8-22
U25LR
U25LR-A
0.5
5
0.6
?6
Power Torque Tools U/UR Optional Accessories Note 2. U500CN, 1000CN, and UR500CN are pistol type with trigger mechanism.
UR500CN
10
20-50
U50R
200-500
950
1.0
#3
1.45
U50R-A
1.0
15-45
U120CN
3. Standard bits available in the local market can be used.
4. Counterclockwise rotation has no torque control and it is loosening purpose only.
1. One Touch Joint #130 for U30CN-250CN, ULR120CN, and ULR250CN.
Standard Accessories
2. Bit holder for U1000CN
One Touch Joint (Female)
Applicable Model
Part #
Part #
Applicable Model
Part # Applicable Model Size Torque-?x For torque adjustment Tool Kit for disassembly/assembly for UNITORK
130 PF 1/4 Female 145 U30CN-U120CN 160 U30CN-U250CN
131 U30CN-U250CN PF 1/4 Male 146 U250CN 161 U250CN
132 ?8 Hose Joint 147 U500CN, UR500CN 162 U500CN, UR500CN
163 U1000CN
Hand Cover
Part # Applicable Model
150 U30CN-U120CN
151 U250CN
MG/MF Multiple Unit/ Automatic Straight Pneumatic Graduation Master Valve Operation RoHS
Pneumatic Straight
Style ? Several units used simultaneously with loader
? Fully automatic tightening for complex bolt con?gurations
Direction
Accuracy ±5%
Torque Range Torque Range Torque Range Free Air Hose Overall Bit
S.I. Model [cN·m/N·m] Metric [kgf·cm] American [lbf·in] Speed Pressure Dia. Length Holder Weight
Model
Model
Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. [r.p.m] [Mpa] [mm] [mm] [mm] [kg]
cN·m cN·m kgf·cm kgf·cm
MG120CN 40-120 1 M12G 4-12 0.1 M12G-A 4-10 0.2 720 ?5 287- 0.68
MG250CN 100-250 2.5 M25G 10-25 0.25 M25G-A 8-22 0.5 350 279
N·m N·m 0.4 6.35
MF6N 3-6 0.1 M60F 30-60 1 M60F-A 25-50 1 1000 411- Hex
MF12N ?6 2.0
MF12N 6-12 0.2 M120F 60-120 2 M120F-A 50-100 2 500 403
Note 1. MG/MF is 6.35 HEX bit holder type.
2. For designing a multi-spindle system, check the PCD, minimum distance between the spindles.
3. For ?rst-time user, consult Tohnichi for assistance.
Standard Accessories Torque adjusting key
