Tohnichi Reference Guide 2019
RTD Rotary Slip Adjustable ? Ratcheting mechanism prevents over torque. RoHS
Assembly
Rotary Slip
Graduation
Adjustable
Torque Screwdriver
? Torque easily set with external scale
Direction
Accuracy ±3%
Torque Range Torque Range Torque Range Overall
S.I. Model [cN·m] Metric [kgf·cm] American [ozf·in/lbf·in] Length Weight
Model
Model
Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. [mm] [g]
ozf·in ozf·in
- - - - - - RTD20Z 6-20 0.2 100 50
15-40
- - - - - - - - - - - - - - - - - - RTD40Z 30-150 0.5 110 160
20-80
RTD60CN
RTD80Z
1
80
Torque Screwdriver RTD15CN 20-120 0.1 1.5RTD 0.2-1.5 0.01 RTD1.3I 0.2-1.3 lbf·in 100 160
RTD150Z
130
2
lbf·in
0.01
2-15
50
RTD30CN
0.02
0.4-3
RTD2.6I
0.2
4-30
3RTD
0.02
0.4-2.6
0.05
80
RTD60CN
6RTD
0.05
1-5
1-6
0.5
RTD5I
10-60
110
1
2-12
12RTD
0.1
RTD10I
2-10
0.1
130
RTD120CN
60-260
RTD120CN with Resin Grip
6-22
RTD260CN
6-26
0.5
0.5
320
155
RTD500CN
RTD40I
50RTD
1. Auxiliary tightening tool for RTD500CN is sold separately.
Note 100-500 2 5 26RTD 10-50 0.2 RTD22I 10-40 0.2 150 270
2. Bits are sold separately. Refer to page 11.
Standard Accessories 1. Hook spanner for RTD260CN and RTD500CN
2. Resin grip for RTD120CN and RTD260CN
LTD Adjustable Torque Assembly Adjustable Graduation RoHS
Screwdriver
? Clicks at set torque value
Direction ? Torque easily set with external scale
Accuracy ±3%
Torque Range Torque Range Torque Range Overall
S.I. Model [cN·m] Metric [kgf·cm] American [ozf·in/lbf·in] Length Weight
Model
Model
Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. [mm] [g]
ozf·in ozf·in
- - - - - - LTD20Z 6-20 0.2 100 50
- - - - - - LTD40Z 15-40 0.5
LTD60CN - - - - - - LTD80Z 20-80 1 110 80
- - - - - - LTD150Z 30-150 2 130 160
lbf·in lbf·in
LTD15CN 2-15 0.1 1.5LTD 0.2-1.5 0.01 LTD1.3I 0.2-1.3 0.01 100 50
LTD30CN 4-30 0.2 3LTD 0.4-3 0.02 LTD2.6I 0.4-2.6 0.02
LTD60CN 10-60 0.5 6LTD 1-6 0.05 LTD5I 1-5 0.05 110 80
LTD120CN 20-120 1 12LTD 2-12 0.1 LTD10I 2-10 0.1 130 160
LTD260CN 60-260 2 26LTD 6-26 0.2 LTD22I 6-22 0.2 150 270
LTD120CN with Resin Grip LTD500CN 100-500 50LTD 10-50 LTD40I 10-40 155 320
LTD1000CN 200-1000 5 100LTD 20-100 0.5 LTD90I 20-90 0.5 185 580
LTD2000CN 300-2000 200LTD 30-200 LTD180I 30-180 255 1150
Note 1. Auxiliary tightening tool for LTD500CN and LTD1000CN is available, sold separately.
2. Bits are sold separately. Refer to page 10.
3. Bits for LTD2000CN are Tohnichi original.
Standard Accessories 1. Hook spanner for LTD260CN-LTD2000CN
2. LTD2000CN comes with an auxiliary tightening tool.
3. Resin grip for LTD120CN and LTD260CN
Torque Screwdriver Optional Accessories ADJUSTING TOOL for RTD/LTD HOOK SPANNER
RESIN GRIP for 120CN, 260CN ? Used for zero adjustment for RTD/LTD/MNTD
GRAY GREEN BLUE ? Torque setting for middle and large
size torque screwdriver
Part # Applicable Model
ORANGE
BLACK RED 51 LTD/RTD15CN, 30CN
Applicable Model
For 120CN For 260CN 46 LTD/RTD60CN Part # LTD/RTD260CN, MNTD120CN
LTD/RTD260CN
47
52
Part # Color Applicable Model Part # Color Applicable Model 48 LTD/RTD500CN 53 LTD/RTD500CN, MNTD260CN
850 Orange 856 Orange RTD260CN 49 LTD/RTD1000CN 54 LTD1000CN, MNTD500CN
851 Gray RTD120CN 857 Gray LTD260CN 1046 LTD/RTD120CN 55 LTD2000CN
852 Black LTD120CN 858 Black
853 Green RNTD120CN 859 Green RNTD260CN AUXILIARY TIGHTENING TOOL TORQUE ADJUSTING BAR
854 Red NTD120CN 860 Red NTD260CN for RTD/LTD/RNTD/NTD for RNTD/NTD/RNTDZ
855 Blue 861 Blue
? Make easier for large torque tightening ? Used for torque setting of preset
Resin Grip Dimensions torque screwdriver
120CN 260CN
RTD RNTD RTD RNTD
LTD NTD LTD NTD
Hexagon width across flats 33 41
Maximum value [mm] Part # Applicable Model
Hexagon width across corner 35 44 Part # Applicable Model 42 NTD/RNTD15CN-120CN
Maximum value [mm] 31 LTD/RTD/NTD/RNTD500CN 43 NTD/RNTD260CN, RNTDZ260CN
Length [mm] 67 81 68 32 LTD/NTD1000CN, RTDFH/RNTDFH500CN 44 NTD/RNTD500CN-1000CN, RNTDZ500CN
40 LTD2000CN
Overall Length with torque 130 110 150 110 RTDLS500CN
screwdriver [mm] 1031
RNTDSL500CN
