Tohnichi Reference Guide 2019
FTD Dial Indicating Torque Inspection Dial Indicating Memory Pointer Direct Reading RoHS
Screwdriver with
Memory Pointer ? Ideal for measuring torque
? FTD-S with memory pointer; FTD with preset knob
Direction Accuracy ±3%
Torque Range Torque Range Torque Range Overall Standard Accessory
S.I. Model [cN·m] Metric [gf·cm/kgf·cm] American [ozf·in/lbf·in] Length Weight Bit
Model
Model
Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. [mm] [g] + - Thickness × Width
FTD-S cN·m cN·m gf·cm gf·cm ozf·in ozf·in
FTD2CN-S 0.3-2 0.05 02FTD2-S 30-200 5 FTD3Z2-S 0.5-3 0.1
FTD200CN2-S FTD5CN-S 0.5-5 0.1 05FTD2-S 50-500 10 FTD7Z2-S 1-7 0.2
kgf·cm kgf·cm FTD15Z2-S 2-15 0.5 152 140 Interchangeable bit is
Torque Screwdriver FTD50CN2-S 10-100 1 2 - 5FTD2-S 0.5-5 0.1 - FTD70Z2-S 10-70 lbf·in 272 370 sold separately.
FTD10CN-S
1-10
0.1-1
0.02
0.2
1FTD2-S
0.3-2
FTD20CN-S
FTD30Z2-S
0.05
1
3-20
2FTD2-S
0.5
5-30
5-50
2
Refer to page 11.
lbf·in
-
0.1
-
-
5FTD2-A-S
0.5-5
-
1-10
10FTD2-S
0.2
1-10
10FTD2-A-S
0.2
FTD100CN2-S
30-200
FTD200CN2-S
5
50-400
5-40
5-40
1
10
40FTD2-S
40FTD2-A-S
1
FTD400CN2-S
FTD100CN
N·m N·m 20FTD2-S 3-20 0.5 20FTD2-A-S 3-20 0.5
FTD8N2-S 1-8 0.2 80FTD2-S 10-80 2 80FTD2-A-S 10-70 2 900
FTD16N2-S 3-16 0.5 160FTD2-S 30-160 5 160FTD2-A-S 20-140 5 338 930 # 3 1.2 × 8
FTD cN·m cN·m
FTD50CN 10-50 1 5FTD 1-5 0.1 5FTD-A 1-5 0.1 215 285 # 1 0.7 × 7
FTD100CN 20-100 2 10FTD 2-10 0.2 10FTD-A 1-10 0.2 290
FTD200CN 40-200 5 20FTD 4-20 0.5 20FTD-A 3-20 0.5 263 390 # 2 0.9 × 7
FTD400CN 80-400 10 40FTD 8-40 1.0 40FTD-A 5-40 1 410
Note FTD8N2-S, FTD16N2-S: Square drive type, 6.35mm
Standard Accessories Auxiliary tightening bar for FTD8N2-S and FTD16N2-S
MTD Micro Dial Indicating Inspection Dial Indicating Direct Reading RoHS
Torque Screwdriver
? Low torque capacity version of FTD
Direction ? Requires special size bits
Accuracy ±3%
Torque Range Torque Range Torque Range Overall Standard Accessory
S.I. Model [mN·m] Metric [gf·cm] American [ozf·in] Length Weight Bit
Model
Model
-
Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. [mm] [g] + Thickness × Width
MTD1MN 0.1-1 0.02 10MTD 1-10 0.2 - - - 110 22
MTD2MN 0.3-2 0.05 20MTD 3-20 0.5 - - - 100 21 # 0 0.15 × 1
0.2 × 15
MTD5MN 0.5-5 0.1 50MTD 5-50 1 MTD07Z 0.1-0.7 0.02
MTD5MN MTD10MN 1-10 0.2 100MTD 10-100 2 MTD1.4Z 0.2-1.4 132 23 0.3 × 2
Note MTD models require Tohnichi made bits. Refer to page 10.
STC2-G/-BT Digital Torque Assembly Inspection Digital Direct Reading Ratchet Rechargeable
Screwdriver
? Ideal for tightening and inspection operation RoHS
Direction ? 1000 data memory storage and data output function
? Color LED indicator, White, Blue, Yellow, and Red
Accuracy ±1%
Torque Range Overall
Model Weight
[cN·m] [kgf·cm] [lbf·in] [ozf·in] Length
Standard Version Bluetooth Version Min.-Max. 1digit Min.-Max. 1digit Min.-Max. 1digit Min.-Max. 1digit [mm] [g]
®
STC50CN2-G STC50CN2-G-BT 10-50 0.05 1-5 0.005 1-4.4 0.005 15-70 0.05
STC200CN2-G STC200CN2-G-BT 40-200 0.2 4-20 0.02 4-17 0.02 - - 230 325
STC400CN2-G STC400CN2-G-BT 80-400 0.5 8-40 0.05 8-35 0.05 - -
Note 1. Bits are sold separately. Refer to page 10.
2. Bits size as below
3. Display can be turned upside down with keypad operation.
4. Data output of standard version is through USB only.
5. Data output of Bluetooth version is through USB and Bluetooth . ®
®
6. Contact to Tohnichi for condition of wireless equipment in each country.
Standard Accessories USB cable/384, AC adapter/BA-7, and Battery pack/BP-7. Refer to page 47.
STC200CN2-G White LED light Blue LED light Yellow & Red flashing LED light
80% of target torque Achieving target torque Over torque indication
STC2-G/-BT Specifications STC2-G-BT Communication Specifications [EX.] Torque checking ?gure
for torque screwdriver
®
Accuracy ±1% Bluetooth Version V3.0
Measurement Mode Tightening / Inspection mode Transmitting System AFH
Battery Indicator 4 levels Moduration System GFSK
Judgment Mode Buzzar and LED indicator on upper/lower limit Wireless Output 4dBm
Basic Functions Auto-power off, Auto memory & reset, Auto zero setting Transmission Power Class Class 2
Power Supply Lithium Ion Battery Pro?le SPP
Data Output USB Communication Distance 10m STC2-G
Operating Time approximate 30 hours Operating Time 15 hours
AC adaptor: 5 hours
Recharging Time
USB through PC: 10 hours
9
