Tohnichi Reference Guide 2019
Connecting Cable * The cable length is 2m.

EPP16M3 Printer Connecting Cable
Part # Applicable Model Figure Plug

DOTE4-G (P.51), TDT3-G (P.53), LC3-G (P.54),
383 D-SUB 9 Pin Female
TME2 (P.57), CD5 (P.63)
CTA2-G (P.23), CEM3-G/CEM3-P (P.35), CTB2-G (P.36),
575 R-DT999 (P.63), D-SUB 9 Pin Female

PC Connecting Cable
Part # Applicable Model Figure Plug

CTA2-G (P.23), CEM3-G/CEM3-P (P.35), CTB2-G (P.36),
575 D-SUB 9 Pin Female
R-DT999 (P.63),
CTA2-G (P.23), CEM3-G/CEM3-P (P.35), CTB2-G (P.36),
584 USB A type
R-DT999 (P.63),
585 CPT-G (P.22) D-SUB 9 Pin Female

DOTE4-G (P.51), TDT3-G (P.53), LC3-G (P.54),
383 D-SUB 9 Pin Female
TME2 (P.57), CD5 (P.63)

STC2-G (P.9), ST3-G (P.54),
384 USB A type
ATGE-G (P.55), BTGE-G (P.56)
385 DOTE4-G (P.51), TDT3-G (P.53), LC3-G (P.54) USB A type

Accessories
Quick Charger, Battery Pack, AC Adapter

Quick Charger Battery Pack

Model Applicable Model Figure Model Applicable Model Figure
RoHS CEM3-G/CEM3-P (P.35), CTA2-G (P.23) RoHS CTA2-G (P.23),
BC-3-G CTB2-G (P.36) (100-240V) BP-5 CEM3-G/CEM3-P (P.35), CTB2-G (P.36)

RoHS RoHS
ST3-G (P.54) STC2-G (P.9)
BC-4-2 BP-7
RoHS DOTE4-G (P.51), TDT3-G (P.53),
BP-100-4 LC3-G (P.54), TME2 (P.57), CD5 (P.63)

AC Adapter

Model Applicable Model Figure Model Applicable Model Figure
RoHS DOTE4-G (P.51), TDT3-G (P.53), RoHS
LC3-G (P.54), CD5 (P.63) TME2 (P.57)
BA-6 BA-4
RoHS RoHS
ATGE-G (P.55), BTGE-G (P.56) STC2-G (P.9)
BA-5 BA-7
RoHS
R-BT (P.48), R-BLA (P.30), R-BLE (P.30)
BA-8

46
