Tohnichi Reference Guide 2019
SF/F/FR Beam Type Inspection Beam Direct Reading RoHS
Torque
Wrench ? Direct reading torque wrench with scale plate
? For measuring and tightening applications
Direction
Accuracy ±3%
Torque Range Torque Range Torque Range Overall Square
S.I. Model [cN·m/N·m] Metric [kgf·cm/kgf·m] American [lbf·in/lbf·ft] Length Drive Weight
Model
Model
Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. [mm] [mm] [kg]
cN·m cN·m kgf·cm kgf·cm lbf·in lbf·in
SF40CN 8-40 4SF 0.8-4 4SF-A 0-3.4 115 0.04
SF70CN 10-70 2 7SF 1-7 0.2 7SF-A 0-6 0.2 135 0.05
N·m N·m
SF6N SF1.5N 0.2-1.5 0.05 15SF 2-15 0.5 15SF-A 0-13 0.5 145 6.35 0.07
SF3N 0.5-3 0.1 30SF 5-30 1 30SF-A 0-26 1 175 0.09
SF6N 0.6-6 0.2 60SF 6-60 2 60SF-A 0-50 2 205 0.2
SF12N 2-12 120SF 20-120 120SF-A 0-100 235 0.25
F23N 3-23 0.5 230F 30-230 5 230F-A 0-200 5 295 9.5 0.4
F46N 5-46 1 460F 50-460 10 460F-A 0-400 10 355 0.6
lbf·ft lbf·ft
F92N 10-92 920F 100-920 920F-A 10-66 400 0.95
F130N 20-130 2 1300F 200-1300 20 1300F-A 10-95 2 445 12.7 1.2
F92N F190N 30-190 1900F 300-1900 50 1900F-A 25-135 490 1.5
5 kgf·m kgf·m
F280N 50-280 2800F 5-28 0.5 2800F-A 30-200 5 565 2.2
F420N 70-420 4200F 7-42 4200F-A 30-300 825 19.0 3.5
F560N 100-560 10 5600F 10-56 1 5600F-A 50-400 945 4.0
F700N 100-700 7000F 10-70 7000F-A 50-500 10 1175 6.0
F850N 100-850 8500F 10-85 8500F-A 60-600 1410 7.8
F1000N 100-1000 10000F 10-100 10000F-A 70-700 1640 8.8
FR1050N 100-1050 20 10500FR 10-105 2 10500FR-A 100-750 20 835 25.4 8
FR1400N 200-1400 14000FR 20-140 14000FR-A 100-1000 981 11.5
FR2100N 300-2100 50 21000FR 30-210 5 21000FR-A 200-1500 1148 14.5
FR2800N 300-2800 28000FR 30-280 28000FR-A 200-2000 50 1292 20
FR4200N 400-4200 1. FR models are supplied upon request. 10 42000FR-A 300-3000 1460 38.1 28
40-420
42000FR
100
400-4300
60000FR-A
30
1624
600-6000
FR6000N
60-600
60000FR
Torque Wrench for Quality Inspection Interchangeable 2. FR models require winch or mechanical loading device.
Note
3. For models having over 25.4mm square drive, use with a through-hole socket.
4. Accuracy of American models is warranted from 20% of max. torque.
CSF/CF
Beam
Interchangeable
Inspection
Head Type Beam
Type Torque ? Interchangeable head version of SF/F Direct Reading RoHS
Direction ? For measuring and tightening applications
Wrench Accuracy ±3%
Torque Range Torque Range Torque Range Overall
Head [N·m] Metric [kgf·cm/kgf·m] American [lbf·in/lbf·ft] Weight
Size S.I. Model Model Model Length
Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. [mm] [kg]
N·m N·m kgf·cm kgf·cm lbf·in lbf·in
CSF7N×8D 1-7 0.2 70CSF 10-70 2 70CSF-A 10-60 2 220 0.2
8D
CSF14N×8D 2-14 0.5 140CSF 20-140 5 140CSF-A 20-120 5 250 0.25
10D CF25N×10D 5-25 1 250CF 50-250 10 250CF-A 40-220 10 320 0.4
CSF7N×8D 12D CF50N×12D 10-50 500CF 100-500 500CF-A 80-420 20 380 0.6
2 20 lbf·ft lbf·ft
15D CF100N×15D 10-100 1000CF 100-1000 1000CF-A 6-70 2 435 1.0
19D CF150N×19D 20-150 1500CF 200-1500 50 1500CF-A 15-110 480 1.3
5 kgf·m kgf·m
CF230N×22D 30-230 2300CF 3-23 0.5 2300CF-A 20-160 5 530 1.6
22D
CF25N×10D CF420N×22D 70-420 10 4200CF 7-42 1 4200CF-A 30-300 725 3.1
32D CF850N×32D 100-850 20 8500CF 42-85 2 8500CF-A 60-600 20 1260 7.1
Note 1. Overall length does not include interchangeable head.
2. PH (Pipe wrench head) type interchangeable head is not available.
3. Interchangeable heads are optional.
QF/QFR Ratchet Head Inspection Beam Ratchet Head Direct Reading RoHS
Beam Type
Torque Wrench ? Fixed ratchet head flat beam style
Direction ? Ideal for working in narrow spaces
Accuracy ±3%
Torque Range Torque Range Torque Range Overall Square
S.I. Model [N·m] Metric [kgf·cm/kgf·m] American [lbf·in/lbf·ft] Length Drive Weight
Model
Model
Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. [mm] [mm] [kg]
kgf·cm kgf·cm lbf·in lbf·in
QF60N 6-60 1 600QF 60-600 10 600QF-A 0-520 10 455 9.5 0.8
lbf·ft lbf·ft
QF120N 10-120 2 1200QF 100-1200 20 1200QF-A 6-86 2 515 12.7 1.2
QF220N 30-220 5 2200QF 300-2200 50 2200QF-A 25-160 580 1.8
QF120N kgf·m kgf·m 5
QF320N 40-320 3200QF 6-32 3200QF-A 40-230 655 2.6
QF420N 70-420 10 4200QF 7-42 1 4200QF-A 30-300 825 19.0 3.4
QF560N 100-560 5600QF 10-56 5600QF-A 50-400 10 950 4.3
QF700N 100-700 7000QF 10-70 7000QF-A 50-500 1170 6.5
QF850N 100-850 8500QF 10-85 8500QF-A 60-600 1400 8.5
QFR1050N 100-1050 20 10500QFR 10-105 2 10500QFR-A 100-750 20 845 25.4 8.5
QFR1400N 200-1400 14000QFR 20-140 14000QFR-A 100-1000 992 12.5
QFR2100N 300-2100 50 21000QFR 30-210 5 21000QFR-A 200-1500 1158 15.5
QFR2800N 300-2800 28000QFR 30-280 28000QFR-A 200-2000 1305 21
QFR4200N 400-4200 42000QFR 40-420 42000QFR-A 300-3000 50 1473 38.1 30
QFR6000N 600-6000 100 60000QFR 60-600 10 60000QFR-A 400-4300 1624 32
Note 1. QFR models are supplied upon request.
2. QFR models require winch or mechanical loading device.
3. For models having over 25.4mm square drive, use with a through-hole socket.
39
