Tohnichi Reference Guide 2019

The Relationship between Interchangeable Heads and Torque Wrenches ?
Tohnichi?s interchangeable head wrenches have speci?c diameter round Nominal diameter
ends that ?t into corresponding head base openings. Head and wrench ? CL100N×15D
model names include the diameter sizes so heads can be matched to
wrenches that will accept those heads.
For example: SH15D×17 will ?t on CL100N×15D ? Nominal diameter
A variety of different head types (SH, RH, QH, RQH, FH, DH, AH and SH- 15D=?15
N) can be used on one wrench or different types of wrenches such as CL (for ?
tightening) and CEM3 (for inspection) can use the same head that has the SH15D×17
corresponding diameter size.
RH Ring Head

RoHS C Width

1
The RH type ring heads guarantee the safe work as the axes of bolt and RH ring
head are always aligned and prevent the heads will drop.
t RH15D×17
Note: RH8D×5.5 to RH8D×7 are hex shape.
Tohnichi Model Allowable Torque Outside Width Thickness Tohnichi Model Allowable Torque Outside Width Thickness
Head Size (Body Size × Width) [N·m] [kgf·cm] C [mm] t [mm] Head Size (Body Size × Width) [N·m] [kgf·cm] C [mm] t [mm]
RH8D×5.5 1.5 15 10.5 RH19D×14 59 590 22.5 8
RH8D×6 2.4 24 11 5 RH19D×17 100 1000 27 10
RH8D×7 3.6 36 12 6 RH19D×18 28 11
RH8D×8 7.2 72 13.5 RH19D×19 29
8D 166 1660
RH8D×10 12.2 122 15.5 RH19D×21 32 13
RH8D×11 17 7 RH19D×22
RH8D×12 15 140 18 19D RH19D×24 35
RH8D×13 19 RH19D×27 39
RH10D×8 7.2 72 12.5 6 RH19D×30 200 2000 41
RH10D×10 12.2 122 15.5 7 RH19D×32 44 15
RH10D×11 20 200 17 RH19D×34 47
RH10D×12 18 RH19D×36 49
RH10D×13 19 RH19D×41 55
RH10D×14 20 RH22D×19 166 1660 30
10D 14
RH10D×16 22 RH22D×22 34
RH10D×17 25 250 24 8 RH22D×24 255 2550 37 15
RH10D×18 25 RH22D×27 490 4900 41
RH10D×19 26 22D RH22D×30 44
RH10D×21 28 RH22D×32 45
RH10D×22 29 RH22D×34 500 5000 49 17
RH12D×8 7.2 72 15 5 RH22D×36 51
RH12D×10 12.2 122 16 RH22D×41 57
RH12D×11 20 200 18 5.5 RH22D×46 62
RH12D×12 29.5 295 20 6.5 RH27D×22 255 2550 38 14 Accessories
RH12D×13 21 RH27D×24 350 3500 15
RH12D×14 20 RH27D×27 490 4900 42 16
12D 59 590 10
RH12D×16 24 RH27D×30 670 6700 46 19
RH12D×17 25 RH27D×32 750 7500 48
RH12D×18 12 27D RH27D×34 670 6700 51 20
RH12D×19 70 700 26 RH27D×36 52 21
RH12D×21 29 13 RH27D×41 58 22
RH12D×22 30 RH27D×46 750 7500 64 24
RH15D×12 RH27D×50 69 26
RH15D×13 29.5 295 19 7 RH32D×27 490 4900 43 16
RH15D×14 59 590 22 8 RH32D×30 670 6700 46.5
RH15D×16 25 RH32D×32 860 8600 49 18
RH15D×17 100 1000 26 10 RH32D×34 52
RH15D×18 RH32D×36 53
15D RH15D×19 28 32D RH32D×41 59 24
RH15D×21 31 RH32D×46 1200 12000 65
RH15D×22 140 1400 13 RH32D×50 69 27
RH15D×24 34 RH32D×55 75 29
RH15D×27 37 RH32D×60 80
RH15D×30 41
Inch Size Models
Commonly used in the airline industry and for speci?c American product installation and maintenance.
Tohnichi Model Inner Width Allowable Torque Outside Width C Thickness t Tohnichi Model Inner Width Allowable Torque Outside Width C Thickness t
Head Size (Body Size × Inner Width [in]) [mm] N·m [lbf·in] mm [in] mm [in] Head Size (Body Size × Inner Width [in]) [mm] N·m [lbf·in] mm [in] mm [in]
RH8D×1/4 6.35 3.6 [31] 11 [0.43] 5 [0.20] RH15D×1/2 12.7 29.5 [261] 19 [0.81] 7 [0.28]
RH8D×5/16 7.94 7.2 [63] 13.5 [0.53] 6 [0.24] RH15D×9/16 14.29 22 [0.87]
8D 59 [522] 8 [0.31]
RH8D×3/8 9.53 12.2 [108] 15 [0.59] 7 [0.28] 15D RH15D×5/8 15.88 25 [0.98]
RH8D×7/16 11.11 15 [132] 17 [0.67] RH15D×11/16 17.46 100 [885] 26 [1.06] 10 [0.39]
RH10D×1/4 6.35 7.2 [64] 11 [0.43] 6 [0.24] RH15D×3/4 19.05 140 [1239] 28 [1.10] 13 [0.51]
RH10D×5/16 7.94 12.5 [0.49]
RH10D×3/8 9.53 12.2 [108] 15.5 [0.61] 7 [0.28]
10D
RH10D×7/16 11.11 17 [0.67]
RH10D×1/2 12.7 25 [221] 19 [0.75] 8 [0.31]
RH10D×9/16 14.29 20 [0.79]
RH12D×3/8 9.53 12.2 [108] 16 [0.63] 5 [0.20]
RH12D×7/16 11.11 20 [177] 18 [0.71] 5.5 [0.22]
12D RH12D×1/2 12.7 29.5 [261] 21 [0.83] 6.5 [0.26]
RH12D×9/16 14.29 20 [0.79]
RH12D×5/8 15.88 59 [522] 24 [0.94] 10 [0.39]
