P. 18
Tohnichi Reference Guide 2019
PQL Ratchet Head Type Assembly Pre-Lock Ratchet Head Graduation RoHS
Pre-Lock Torque
Wrench ? External scale, set by a hex key
Direction
PQL100N4
Accuracy ±3%
PQL Optional Accessories Torque Range Torque Range Torque Range Overall Square
S.I. Model [N·m] Metric [kgf·cm/kgf·m] American [lbf·in/lbf·ft] Length Drive Weight
Model
Model
Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. [mm] [mm] [kg]
kgf·cm kgf·cm lbf·in lbf·in
PQL10N 2-10 0.1 100PQL 20-100 1 PQL50l-2A 10-50 0.5 190 6.35 0.19
PQL15N 3-15 150PQL 30-150 PQL100l-2A 20-100 1
PQL25N 5-25 0.25 225PQL 50-250 2.5 225PQL-A 50-200 2.5 215 9.53 0.25
PQL50N 10-50 0.5 450PQL 100-500 5 450PQL-A 100-400 5 260 0.40
842 846 lbf·ft lbf·ft
Carrying Case (P.45) PQL100N4 20-100 1 900PQL4 200-1000 10 900PQL4-A 15-75 1 320 0.65
Applicable Model Weight PQL140N 30-140 1400PQL 300-1400 1400PQL-A 30-100 385 12.7 0.75
Part # PQL200N4 40-200 1800PQL4 400-2000 20 1800PQL4-A 30-150 2 470 1.40
Dimension [mm] [kg]
50N-100N4 kgf·m kgf·m
842 H60 × W400 × D70 0.25 PQL280N 40-280 2 2800PQL 4-28 0.2 - - - - - - 670 19.05 2.0
Torque Wrench for Assembly 846 H170 × W500 × D100 0.36 Standard Accessories Hex key for torque adjustment
6-42
60-420
PQL420N
3.4
4200PQL
975
140N-200N4
0.36
843
H60 × W520 × D80
200N and below
1.0
PQLLS
280N and below
? PQL style with Limit Switch output
RoHS
847
H170 × W740 × D100
assembly processes
Refer to page 28. ? Wired Error-Proo?ng, Pokayoke, system for
PQL Protective Head Cover (P.45)
POKA Patrol, Count Checker
CNA-4mk3
Refer to page 27.
PQLZ Pre-Lock Adjustable Assembly Pre-Lock Ratchet Head Graduation Vinyl Coating Insulated
Insulated Torque
Direction Wrench ? Insulated casing prevents electrical shocks.
? Specialized version of PQL
Accuracy ±3%
Torque Range Torque Range Overall Square
S.I. Model [N·m] Metric [kgf·cm] Length Drive Weight
Model
Min.-Max. Grad. Min.-Max. Grad. [mm] [mm] [kg]
PQLZ25N 5-25 0.25 225PQLZ 50-225 2.5 227 9.5 0.28
PQLZ100N4 20-100 1 900PQLZ4 200-900 10 340 12.7 0.80
PQLZ100N4
Standard Accessories Hex key for torque adjustment
QSPZ Preset Insulated Assembly Preset Vinyl Coating Insulated
Torque Wrench
Direction ? Insulated design suited for use in electric shock hazard conditions
? Ideal for electric car assembly, connection of battery terminal wiring work etc.
Accuracy ±3%
Torque Range Overall Square
Model [N·m] [kgf·cm] [lbf·in] Length Drive Weight
Min.-Max. Min.-Max. Min.-Max. [mm] [mm] [kg]
QSPZ25N 5-25 50-250 50-200 227 9.5 0.28
QSPZ100N4 20-100 200-1000 100-750 334 12.7 0.8
Note 1. A torque wrench tester is necessary for torque adjustment. Specify required set torque when you order.
QSPZ25N 2. Adjusting tools for QSPZ are sold separately.
3. Sockets are sold separately. Refer to page 40.
4. Sockets are not insulation coating.
CLWP Water Proof and Assembly Pre-Lock Interchangeable Water/Dust Proof
Dust Free Torque
Direction Wrench ? Waterproof and Dustproof torque wrench meets IP55/IP57 rating
? Washable torque wrench
? Anticorrosion coating
NEW
Accuracy ±4%
Torque Range Overall Note
Head Model [N·m] Weight
Size Length 1. Overall length does not include interchangeable head.
Min.-Max. Grad. [mm] [kg] 2. PH type interchangeable head/p.44 is not applicable.
NEW CLWP15NX10D 5-15 3. Interchangeable heads are optional.
10D 0.25 220.5 0.3 Refer to page 42-45.
NEW CLWP25NX10D 10-25 4.Waterproof and dustproof test meets IP55/IP57 by
CLWP50NX12D NEW 12D CLWP50NX12D 20-50 0.5 243 0.5 in-house test.
NEW CLWP100NX15D 40-100 1 333.5 0.7
15D CLWP140NX15D 60-140 378.5 0.8
NEW
NEW CLWP200NX19D 80-200 2 457.5 1.4
CLWP Optional Accessories
CPQH interchangeable ratchet head CPQH12D
NEW Corrosion-resistant
15
