Tohnichi Reference Guide 2019
CL/CLE2 Interchangeable Assembly Adjustable Interchangeable Graduation RoHS
Head Type
Adjustable ? Interchangeable Head can be easily exchanged.
Direction Torque Wrench ? Torque value easily set with external scale and knob
CL2N×8D
Interchangeable Head
CLE850N2×32D CL100N×15D
Accuracy ±3%
SH AH RH Torque Range Torque Range Torque Range
Head S.I. Model [N·m] Metric [kgf·cm/kgf·m] American [lbf·in/lbf·ft] Overall Weight
Length
Size Model Model
Min.-Max. Grad. Min.-Max. Grad. Min.-Max. Grad. [mm] [kg]
CL N·m N·m kgf·cm kgf·cm lbf·in lbf·in
CL2N×8D 0.4-2 0.02 20CL 4-20 0.2 CL15I×8D 3-15 0.1
QH RQH DH CL5N×8D 1-5 0.05 50CL 10-50 0.5 CL30I×8D 6-30 0.2 174 0.24
8D
CL10N×8D 2-10 0.1 100CL 20-100 1 CL50I×8D 10-50 0.5 199 0.26
CL15N×8D 3-15 150CL 30-150 CL100I×8D 20-100
10D CL25N5×10D 5-25 0.2 225CL5 50-250 2.5 CL200I×10D 50-200 2.5 216 0.3
12D CL50N×12D 450CL3 450CL3-A 100-400 230
HH SH-N FH CL50N×15D 10-50 0.5 500CL3 100-500 5 500CL3-A 100-450 5 235 0.37
CL100N×15D 20-100 900CL3 200-1000 900CL3-A 200-800 10 310 0.52
15D Torque Wrench for
1 10 lbf·ft lbf·ft Assembly
CL140N×15D 30-140 1400CL3 300-1400 1400CL3-A 30-100 1 370 0.67
CL/CL-MH Optional Accessories 19D CL200N×19D 40-200 1800CL3 400-2000 20 1800CL3-A 30-150 455 1.2
2 kgf·m kgf·m 2
CL280N×22D 40-280 2800CL3 4-28 2800CL3-A 30-200 655 1.8
22D 0.2
CL420N×22D 60-420 4200CL2 6-42 4200CL2-A 60-300 940 3.1
CLE2 N·m N·m kgf·m kgf·m lbf·ft lbf·ft
CLE550N2×27D 100-550 5500CLE2 10-55 CLE400F×27D 100-400 1148 3.9
27D
CLE750N2×27D 150-750 5 7500CLE2 15-75 0.5 CLE550F×27D 150-550 5 1291 4.9
CLE850N2×32D 200-850 8500CLE2 20-85 CLE600F×32D 150-600 1297 5.1
32D CLE1200N2×32D 300-1200 12000CLE2 30-120 CLE900F×32D 200-900 1464 6.9
842 846
Note 1. Overall length does not include interchangeable head. Interchangeable heads are optional.
Carrying Case (P.45) 2. PH type interchangeable head/p.44 is not applicable.
3. CL2N - CL25N5 are yellow/black resin grips. CL50N - CL280N are black resin grips.
Applicable Model 4. CL420N and CLE550N2-CLE1200N2 are knurled handles.
Part # Dimension [mm] 5. CLE2 models with built-in Adjusting Handle
CL50N×12D/15D, CL50N×12D/15D-MH,
842 CL100N×15D-MH H60 × W400 × D70
CL140N×15D/-MH, CL200N×19D/-MH CLLS RoHS
843 H60 × W520 × D80
CL200N×19D, CL200N×19D and below ? CL style with Limit Switch output
846 H170 × W500 × D100
CL280N×22D, CL280N×22D-MH and below ? Wired Error-Proo?ng, Pokayoke, system for assembly processes
847 H170 × W740 × D100
S.I. Model Metric Model
CLMS2N×8D-MH 20CLMS-MH POKA Patrol, Count Checker
CLMS5N×8D-MH 50CLMS-MH
CLMS10N×8D-MH 100CLMS-MH CNA-4mk3
CLMS10N×8D 100CLMS
CLMS15N×8D 150CLMS Refer to page 27.
CLMS15N×8D-MH 150CLMS-MH
CLLS25N5×10D 225CL5LS
Color Cap CLLS50N×12D 450CL3LS
Part # Color Applicable Model CLLS50N×15D 500CL3LS * Sold separately
CLLS100N×15D
900CL3LS
879 Red CLLS140N×15D 1400CL3LS
CL2N×8D, CL5N×8D
880 Blue CL10N×8D, CL15N×8D CLLS200N×19D 1800CL3LS
881 Green CL25N5×10D CLLS280N×22D 2800CL3LS
882 Black CLLS420N×22D 4200CL2LS
CL-MH Interchangeable Assembly Adjustable Interchangeable Graduation RoHS
Head Type
Direction Adjustable Torque ? Knurled metal handle version of CL
? Ideal for oily working conditions
Wrench with Metal
Handle Torque Range Torque Range Torque Range Accuracy ±3%
Head S.I. Model [N·m] Metric [kgf·cm/kgf·m] American [lbf·in] Overall Weight
Length
Size Min.-Max. Grad. Model Min.-Max. Grad. Model Min.-Max. Grad. [mm] [kg]
kgf·cm kgf·cm lbf·in lbf·in
CL2N×8D-MH 0.4-2 0.02 20CL-MH 4-20 0.2 CL15I×8D-MH 3-15 0.1 140 0.13
CL100N×15D-MH 8D CL5N×8D-MH 1-5 0.05 50CL-MH 10-50 0.5 CL30I×8D-MH 6-30 0.2
CL10N×8D-MH 2-10 0.1 100CL-MH 20-100 1 CL50I×8D-MH 10-50 0.5 175 0.16
CL15N×8D-MH 3-15 150CL-MH 30-150 CL100I×8D-MH 20-100 1
10D CL25N×10D-MH 5-25 0.25 225CL-MH 50-250 2.5 - - - 200 0.22
12D CL50N×12D-MH 10-50 0.5 450CL-MH 100-500 5 - - - 230 0.37
CL50N×15D-MH 500CL-MH - - - 235
15D CL100N×15D-MH 20-100 900CL-MH 200-1000 - - - 310 0.52
CL5N×8D-MH CL140N×15D-MH 30-140 1 1400CL-MH 300-1400 10 - - - 370 0.67
19D CL200N×19D-MH 40-200 1800CL-MH 400-2000 20 - - - 455 1.2
2 kgf·m kgf·m
22D CL280N×22D-MH 40-280 2800CL-MH 4-28 0.2 - - - 655 1.6
Note 1. Overall length does not include interchangeable head.
2. PH type interchangeable head/p.44 is not applicable.
3. Interchangeable heads are optional.
12
